Thermo Scientific ADR1500 Area Dust Monitor
Thermo Scientific

Thermo Scientific ADR1500 Area Dust Monitor

Pine Item #51352

The Thermo Scientific Model ADR1500 Dust Monitor utilizes the highly sensitive light-scattering photometer (nephelometer) technology as used in the Thermo Scientific™ pDR series. The intensity of the light scattered by airborne particles passing through the sensing chamber is linearly proportional to their concentration. This optical configuration produces an optimal response to particles, providing continuous measurements of the concentrations of airborne particles for total particulate and cut-points ranging from PM10 down to PM1.

The ADR1500 incorporates a temperature and relative humidity (RH) sensor coupled with an internal heater to mitigate the positive bias with elevated ambient RH. Additionally, the flow control is truly volumetric and is maintained through digital feedback of the onboard barometric pressure sensor, temperature sensor and calibrated differential pressure across a precision orifice. The principles of true volumetric flow, as incorporated by the ADR1500, result in an accurate sample volume and precise particle cut-point.

Additional Information:

  • The measured concentration of particulate matter is displayed in real-time on the two-line LCD readout display
  • Additional values can be displayed: run start time and date, time-averaged concentrations, elapsed run time and many more
  • Flexible power capabilities allow the ADR1500 to operate on AC (100-240 VAC), external DC (12-24 VDC) or an internal battery
  • Communications options are available for USB, RS-232, analog and wireless capability
  • The compact and durable instrument is ready for rapid deployment and unattended operation
  • A top-mounted handle allows for easy transport and installation with mounting options available for wall, post or tripod locations
Features:

Volumetric flow control

Modular optics and long-life primary HEPA filter for simple servicing

Multiple power and communications capabilities

Durable weather-proof IP65 enclosure

Designed for ease of transport and installation

Applications:

Environmental

Quantity must be 1 or more
Equipment available for both rental and purchase
Request a Quote

Specifications

Technical Specifications

Concentration measurement rangee 0.001 to 400 mg/m3 (auto-ranging)
Flow rate1.1 × 10-6 to 0.6m-1 (approximately) @ λ = 880nm
Precision/Repeatability± 2% of reading or ± 0.005 mg/m3 , whichever is larger, for 1-second averaging time
Accuracy± 5% of reading (± precision) traceable to SAE fine test dust
Resolution0.1 μg/m3
Particle size range of maximum response0.1 to 10 μm
Logged dataAveraged concentrations, temperature, RH, barometric pressure, time/date, and data point number
